Component: Keyfob

• Manufacturer: Marquardt GmbH
• Model: UK1
• Operating Frequency:

  UWB: 5-9 GHz

  NFC: 13.56 MHz (passive tag)

  BLE: 2.4 GHz

• FCC ID: IYZUK1

  IC: 2701A-UK1

• Maximum Transmit Power: UWB: ≤ -41.3 dB/MHz

  BLE: ≤ -1 dBm

Component: NFC MQD Reader

• Manufacturer: Marquardt GmbH
• Model: UR1
• Operating Frequency: 13.56 MHz
• FCC ID: IYZUR1

  IC: 2701A-UR1

• Maximum Transmit Power: UWB: ≤ 42 dBuA/m

Component: NFC MQD

• Manufacturer: Marquardt GmbH
• Model: UR2
• Operating Frequency: 13.56 MHz
• FCC ID: IYZUR2

  IC: 2701A-UR2

• Maximum Transmit Power: UWB: ≤ 42 dBuA/m

Component: UWB/BT Anchor MQD

• Manufacturer: Marquardt GmbH
• Model: MUB1
• Operating Frequency: UWB: 5-9 GHz, BLE: 2.4 GHz
• FCC ID: IYZMUB1

  IC: 2701A-MUB1

• Maximum Transmit Power: UWB: ≤ -40 dBm/ 0.001 mW

  BLE: ≤ -3.19dBm / 0.48mW

Component: UWB/BT Anchor MQD

• Manufacturer: Marquardt GmbH
• Model: MU3
• Operating Frequency: 5-9 GHz
• FCC ID: IYZMU3

  IC: 2701A-MU3

• Maximum Transmit Power: ≤ -40 dBm/ 0.001 mW

Component: Homelink Universal Garage Door Transmitter

• Manufacturer: Gentex Corp
• Model: ADHL5D
• Operating Frequency: 286-440 MHz, 902-928 MHz
• FCC ID: NZLADHL5D
• IC: 4112A-ADHL5D
• Maximum Transmit Power: 286-440MHz: ≤ 85dBuV, 902.25-926.75MHz: -0.97 dBm / 0.8 mW

Component: Long-Range Radar

• Manufacturer: HL Klemove Corp.
• Model: LRR-30
• Operating Frequency: 7.6-7.7 GHz
• FCC ID: 2A3OZ-LRR-30

  IC: 27992-LRR30

• Maximum Transmit Power: ≤ 27.18 dBm / 522 mW

Component: Short Range Radar

• Manufacturer: HL Klemove Corp.
• Model: SRR-40
• Operating Frequency: 76-77 GHz
• FCC ID: 2A3OZ-SRR4IS

  IC: 27992-SRR4IS

• Maximum Transmit Power: ≤ 30.72 dBm / 1180.3 mW

Component: Wireless Phone Charger

• Manufacturer: Lucid USA, Inc.
• Model: J48800
• Operating Frequency: 127.7kHz
• FCC ID: 2AXZJ-J48800

  IC: 27970-J48800

• Maximum Transmit Power: ≤ 8.76 dBuA

Component: Unified Cockpit Controller

• Manufacturer: Lucid USA, Inc.
• Model: P21-K2C000
• Operating Frequency: 2.402-2.480 GHz,

  5.150 GHz - 5.25 GHz,

  5.725 GHz - 5.85 GHz

• FCC ID: 2AXZJ-K2B100

  IC: 27970-K2B100

• Maximum Transmit Power:

  FCC/IC: 2.4GHz : ≤ 15.3 dBm / 33.88 mW

  5.725-5.85GHz : ≤ 19.5 dBm / 89.13 mW

  FCC: 5.15-5.25GHz: ≤ 20.7 dBm / 117.49 mW

  IC: 5.15-5.25GHz: ≤ 9.5 dBm / 8.91mW

Component: Interior Radar Controller

• Manufacturer: CubTEK Inc.
• Model: B122-084
• Operating Frequency: 62 GHz
• FCC ID: 2AN3B-B122084

  IC: 23344- B122084

• Maximum Transmit Power: ≤ 11.53 dBm / 14.2 mW

Component: Telematics Control Unit

• Manufacturer: Lucid USA, Inc.
• Model: P11-K290G0-02
• Operating Frequency: 1850~1910MHz, 1710~1755MHz, 824~849MHz, 2500~2570MHz, 699~716MHz, 777~787MHz, 1850~1910MHz, 1710~1755MHz, 824~849MHz, 824.2~849.2MHz, 850.2~1909.8MHz,2400MHz ~ 2483.5MHz, 5150MHz ~ 5250MHz, 5725MHz ~ 5850MHz
• FCC ID: 2AXZJ-CTX0710W3

  IC: 27970-CTX0710W3

• Maximum Transmit Power:

  FCC/IC:

  LTE band 2(1850~1910MHz)≤ 25.7 dBm / 371.54 mW,

  LTE band 4(1710~1755MHz) ≤ 25.7 dBm / 371.54 mW,

  LTE band 5(824~849MHz) ≤ 25.7 dBm / 371.54 mW,

  LTE band 7(2500~2570MHz) ≤ 25.7 dBm / 371.54 mW,

  LTE band 12(699~716MHz) ≤ 25.7 dBm / 371.54 mW,

  LTE band 13(777~787MHz) ≤ 25.7 dBm / 371.54 mW,

  3G band 2(1850~1910MHz) ≤ 26.7 dBm / 467.74 mW,

  3G band 4(1710~1755MHz) ≤ 26.7 dBm / 467.74 mW,

  3G band 5(824~849MHz) ≤ 26.7 dBm / 467.74 mW,

  2G GSM 850(824.2~849.2MHz) ≤ 35.5 dBm / 3548.13 mW,

  2G GSM 1900(1850.2~1909.8MHz) ≤ 31.5 dBm / 1412.54mW,

  WiFi 2.4G (2400MHz ~ 2483.5MHz) ≤ 30 dBm / 1000 mW,

  WiFi 5G (5725MHz ~ 5850MHz) ≤30 dBm / 1000 mW,

  FCC:

  WiFi 5G (5150MHz ~ 5250MHz) ≤ 30 dBm / 1000 mW,

  IC :

  WiFi 5G (5150MHz ~ 5250MHz) ≤ 14.7 dBm / 29.51 mW E.I.R.P

Component: Tire Pressure Monitoring System

• Manufacturer: Continental Automotive GmbH
• Model: TIS-01
• Operating Frequency: 433.92 MHz
• FCC ID: KR5TIS-01/ IC 7812D-TIS01
• Maximum Transmit Power: ≤ -26.93 dBm / 0.00202 mW

FCC and ISED Notes: Wireless Charger - Lucid USA, Inc.

Model: J48800

FCC ID: 2AXZJ-J48800

IC: 27970-J48800

US:

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

Federal Communication Commission (FCC) Radiation Exposure Statement

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End user must follow the specific operating instructions for satisfying RF exposure compliance.

Canada:

CAN ICES-3 (B)/NMB-3(B)

This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions:

• This device may not cause interference.
• This device must accept any interference, including interference that may cause undesired operation of the device.

L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes :

• L’appareil ne doit pas produire de brouillage;
• L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.

Radiation Exposure Statement:

The product comply with the Canada portable RF exposure limit set forth for an uncontrolled environment and are safe for intended operation as described in this manual. The further RF exposure reduction can be achieved if the product can be kept as far as possible from the user body or set the device to lower output power if such function is available.

Informations concernant l’exposition aux fréquences radio (RF)

Le produit est conforme aux limites d’exposition pour les appareils portables RF pour les Etats-Unis et le Canada établies pour un environnement non contrôlé. Le produit est sûr pour un fonctionnement tel que décrit dans ce manuel. La réduction aux expositions RF peut être augmentée si l’appareil peut être conservé aussi loin que possible du corps de l’utilisateur ou que le dispositif est réglé sur la puissance de sortie la plus faible si une telle fonction est disponible.

FCC and ISED Notes: TPMS System – Continental Automotive GmbH

Model: TIS-01

FCC ID: KR5TIS-01 IC: 7812D-TIS01

US:

FCC Statements

FCC § 15.19 Labelling requirements

This device complies with part 15 of the FCC Rules and Industry Canada license- exempt RSS standard(s). Operation is subject to the following two conditions:

1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause undesired operation.

FCC § 15.21 Information to user

Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

Canada:

ISED RSS-Gen Notice

This device contains license-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s license-exempt RSS(s). Operation is subject to the following two conditions: This device may not cause interference, and this device must accept any interference, including interference that may cause undesired operation of the device.

L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes: L’appareil ne doit pas produire de brouillage; L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.

FCC and ISED Notes: Universal Garage Door Opener Transmitter – Gentex Corp.

Model: ADHL5D

FCC ID: NZLADHL5D

IC: 4112A-ADHL5D

FCC (USA) and IC (Canada):

This device complies with FCC rules part 15 and Industry Canada RSS-210. Operation is subject to the following two conditions:

1. This device may not cause harmful interference, and
2. This device must accept any interference that may be received, including interference that may cause undesired operation.

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End users must follow the specific operating instructions for satisfying RF exposure compliance. This transmitter must be at least 20cm from the user and must not be co-located or operating in conjunction with any other antenna or transmitter.

ISED RSS-Gen Notice

This device contains license-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s license-exempt RSS(s). Operation is subject to the following two conditions:

1. This device may not cause interference.
2. This device must accept any interference, including interference that may cause undesired operation of the device.

L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes:

1. L’appareil ne doit pas produire de brouillage;

2. L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.

FCC and ISED Notes: Long Range Radar - HL Klemove Corp

Model: LRR-30

FCC ID: 2A3OZ-LRR30

IC: 27992-LRR30

US:

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAUTION TO USERS Changes or modifications not expressly approved by the party responsible for compliance could void the user`s authority to operate the equipment.

Canada :

This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions:

1. this device may not cause interference, and
2. this device must accept any interference,including interference that may cause undesired operation of the device.

Le présent appareil est conforme aux CNR. d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes:(1) l'appareil ne doit pas produire de brouillage, et(2) l'utilisateur de l'appareil doit accepter toutbrouillage radioélectrique subi, même si le brouillage est susceptible d'en com≤ -26.93 dBm / 0.00202 mWSeppromettre le fonctionnement.

FCC and ISED Notes: Short Range Radar - HL Klemove Corp.

Model: SRR-40

FCC ID: 2A3OZ-SRR4IS

IC: 27992-SRR4IS

US:

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAUTION TO USERS Changes or modifications not expressly approved by the party responsible for compliance could void the user`s authority to operate the equipment.

Canada:

This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions:

1. this device may not cause interference, and
2. this device must accept any interference,including interference that may cause undesired operation of the device.

Le présent appareil est conforme aux CNR. d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes:(1) l'appareil ne doit pas produire de brouillage, et(2) l'utilisateur de l'appareil doit accepter toutbrouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.

FCC and ISED Notes: Interior Radar – CubTEK Inc

Model: B122-084

FCC ID: 2AN3B-B122084

IC: 23344- B122084

US:

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

1. This device may not cause harmful interference, and
2. this device must accept any interference received, including interference that may cause undesired operation.

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 2.5cm between the radiator and the vehicle passengers’ body.

Canada:

This device contains licence-exempt transmitter(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions:

1. This device may not cause interference,
2. This device must accept any interference, including interference that may cause undesired operation of the device.

L’émetteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes :

1. L’appareil ne doit pas produire de brouillage;
2. L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.

This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 2.5cm between the radiator and the vehicle passengers’ body.

Cet équipement est conforme aux limites d'exposition aux radiations IC RSS-102 définies pour un environnement non contrôlé. Cet équipement doit être installé et utilisé avec une distance minimale de 2,5 cm entre le radiateur et les passagers du véhicule.

FCC and ISED Notes: Keyfob, NFC MQD Reader, NFC MQD, UWB/BT ANCHOR MQD and UWB ANCHOR MQD - Marquardt GmbH

Keyfob Model: UK1

FCC ID:IYZUK1

IC: 2701A-UK1

NFC MQD Reader Model: UR1

FCC ID:IYZUR1

IC: 2701A-UR1

NFC MQD Model: UR2

FCC ID:IYZUR2

IC: 2701A-UR2

UWB Anchor MQD Model: MU3,

FCC ID: IYZMU3

IC: 2701A-MU3

UWB/BT Anchor MQD Model: FCC ID: IYZMUB1

IC: 2701A-MUB1

US:

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause undesired operation.

Changes or modifications made to this equipment not expressly approved by (manufacturer name) may void the FCC authorization to operate this equipment.

Radio frequency radiation exposure Information:

The radiated output power of the device is far below the FCC radio frequency exposure limits. Nevertheless, the device shall be used in such a manner that the potential for human contact during normal operation is minimized.

Canada:

This device complies with Industry Canada licence-exempt RSS standard. Operation is subject to the following two conditions:

1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause undesired operation.

Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes:

1. l'appareil ne doit pas produire de brouillage, et
2. l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.

This Class [B] digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.

FCC and ISED Notes: Telematics Control Unit– Lucid USA, Inc.

Model: P11-K290G0-02

FCC ID: 2AXZJ-CTX0710W3

IC: 27970-CTX0710W3

FCC Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause undesired operation.

This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter.

For products available in the USA/Canada market, only channel 1-11 can be operated. Selection of other channels is not possible.

IMPORTANT NOTE:

FCC Radiation Exposure Statement:

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20cm between the radiator and your body.

Professional Installation instruction:

1. Professional installer: this product is designed for specific application and needs to be installed by trained personnel. The general user shall not attempt to install or change the setting.
2. External Antenna: use only the antenna(s) that have been approved by the manufacturer. The non-approved antenna(s) may produce unwanted spurious or excessive RF transmitting power that may lead to the violation of FCC limit and is prohibited.

IC Canada

This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions

1. This device may not cause interference.
2. This device must accept any interference, including interference that may cause undesired operation of the device.

L’émetteur/récepteur exempt de licence contenu dans le présent apparel est conforme aux CNR d'Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes:

1. L’appareil ne doit pas produire de brouillage;
2. L’appareil doit accepter tout brouillage radioélectrique subi, méme si le brouillage est susceptible d'en compromettre le fonctionnement.

ISED Radiation Exposure Statement:

This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body.

Cet équipement est conforme aux limites d’exposition aux rayonnements IC établies pour un environnement non contrôlé. Cet équipement doit étre installé et utilisé avec un minimum de 20cm de distance entre la source de rayonnement et votre corps

The transmitter module may not be co-located with any other transmitter or antenna.

Le module émetteur peut ne pas étre coimplanté avec un autre émetteur ou antenne.

CAN ICES-3 (B)/NMB-3(B)

The Country Code Selection feature is disabled for products marketed in the US/ Canada for product available in the USA/Canada market, only channel 1~11 can be operated. Selection of other channels is not possible.

Pour les produits disponibles aux Etats-Unis / Canada du marché, seul le canal 1a 11 peuvent étre exploités. Sélection d'autres canaux n'est pas possible.

This radio transmitter [IC: 27970-CTX0710W3] has been approved by Innovation, Science and Economic Development Canada to operate with the antenna types listed below, with the maximum permissible gain indicated. Antenna types not included in this list that have a gain greater than the maximum gain indicated for any type listed are strictly prohibited.

Le présent émetteur radio [IC: 27970-CTX0710W3] a été approuvé par Innovation, Sciences et Développement économique Canada pour fonctionner avec les types d'antenne énumérés ci dessous et ayant un gain admissible maximal. Les types d'antenne non inclus dans cette liste, et dont le gain est supérieur au gain maximal indiqué pour tout type figurant sur la liste, sont strictement interdits pour l'exploitation de l'émetteur.

Antenna Information:

Note 1: WLAN 2.4G cable loss = 1.8 dB.

Note 2: WLAN 5GHz Band 1 cable loss = 2.2 dB, and 5GHz Band 4 cable loss = 2.3 dB.

Note 3: WWAN cable loss = 1.4 dB (LTE Band 12, LTE Band 13)

WWAN cable loss = 1.5 dB (GSM 850, FDD V, LTE Band 5)

WWAN cable loss = 1.7 dB (PCS 1900, FDD II, FDD IV, LTE Band 2, LTE Band 4/66)

WWAN cable loss = 1.8 dB (LTE Band 7)

Note 4: The EUT has four TX antennas.

For 2.4GHz function:

For IEEE 802.11 b/g/n/VHT/ax mode (1TX/1RX)

Ant. 1 (port 1) could transmit/receive.

For 5GHz function:

For IEEE 802.11 a mode (1TX/1RX)

Support diversity function and pre-tested on each single chain, the worst case was Ant. 2 (port 2) and it was recorded in this report.

For IEEE 802.11 n/ac/ax mode (2TX/2RX)

Ant. 1 (port 1) and Ant. 2 (port 2) could transmit/receive simultaneously.

For WWAN 2G function (1TX/1RX):

Ant. 3 (port 1) could transmit/receive.

For WWAN 3G/ 4G function (1TX/2RX):

Ant. 3 (port 1) could transmit, and Ant. 3 (port 1) and Ant. 4 (port 2) could receive simultaneously.

FCC and ISED Notes: Unified Cockpit Controller – Lucid USA, Inc

Model: P21-K2C000

FCC ID: 2AXZJ-K2B100

IC: 27970-K2B100

FCC Interference Statement

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause undesired operation.

Changes or modifications made to this equipment not expressly approved by Lucid Motors, Inc. may void the FCC authorization to operate this equipment.

FCC Radiation Exposure Statement

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20cm between the radiator and your body.

IC Antenna Statement

Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication.

Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage radioélectrique à l'intention des autres utilisateurs, il faut choisir

le type d'antenne et son gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une communication satisfaisante.

IC Licence exempt

This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions:

1. This device may not cause interference.
2. This device must accept any interference, including interference that may cause undesired operation of the device.

Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio

exempts de licence. L'exploitation est autorisée aux deux conditions suivantes :

1. l'appareil ne doit pas produire de brouillage, et
2. l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.

IC Radiation Exposure Statement

This equipment complies with ISED radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with greater than 20cm between the radiator and your body.

Cet équipement est conforme aux limites d'exposition aux rayonnements ISED établies pour un environnement non contrôlé. Cet équipement doit être installé et utilisé à plus de 20cm entre le radiateur et votre corps.

The Particle Charging Unit (Part numbers P21-M70301-05) have been certified by the California air resource board (CARB).

The product has been tested according to the following standards:

Electrostatic Air Cleaners [UL 867:2011 Ed.

5+R:16Aug2021]

Electrostatic Air Cleaners [CSA

C22.2#187:2020 Ed.5]

This product complies with the maximum allowable concentration of ozone of 0.050 parts per million by volume (ppmv) in a 24-h period.
